Introduction to HPC2N, Kebnekaise and HPC¶

• Welcome page and syllabus: https://hpc2n.github.io/intro-linux/index.html
  • Also link at the House symbol at the top of the page.

HPC2N¶

HPC2N provides state-of-the-art resources and expertise:

• Scalable and parallel HPC
• Large-scale storage facilities (Project storage (Lustre), SweStore, Tape)
• Grid and cloud computing (WLCG NT1, Swedish Science Cloud)
• National Data Science Node in ”Epidemiology and Biology of Infections” (Data-Driven Life Science - DDLS)
• Software for e-Science applications
• All levels of user support
  • Primary, advanced, dedicated
  • Application Experts (AEs)

HPC2N partners¶

HPC2N is hosted by:

Partners:

HPC2N funding and collaborations¶

Funded mainly by Umeå University, with contributions from the other HPC2N partners.

Involved in several projects and collaborations:

HPC2N training and other services¶

• User support (primary, advanced, dedicated)
  • Research group meetings @ UmU
  • Also at the partner sites
  • Online “HPC2N fika”
• User training and education program
  • 0.5 – 5 days; presentations and ready-to-run exercises
  • intro courses: our system, Linux, R, Python, Julia, Matlab, Git
  • intermediate courses
  • • Parallel programming and tools (OpenMP, MPI, debugging, perf. analyzers, Matlab, R, MD simulation, ML, GPU, …)
• Courses this fall
  • Introduction to Linux, 16 September 2024
  • Introduction to HPC2N and Kebnekaise, 16 September 2024
  • Basic Singularity, 16 October 2024
  • Introduction to running R, Python, Julia, and Matlab in HPC, 22-25 October 2024
  • Introduction to Git, 25-29 November 2024
  • Using Python in an HPC environment, 5-6 December 2024
  • Updated list: https://www.hpc2n.umu.se/events/courses
• Workshops and seminars
• NGSSC / SeSE & university courses

HPC2N personnel¶

Management:

• Paolo Bientinesi, director
• Björn Torkelsson, deputy director
• Lena Hellman, administrator

Application experts:

• Jerry Eriksson
• Pedro Ojeda May
• Birgitte Brydsö
• Åke Sandgren

Others:

• Mikael Rännar (WLCG coord)
• Research Engineers under DDLS, HPC2N/SciLifeLab
  • Paul Dulaud, System Developer, IT
  • Abdullah Aziz, Data Engineer
  • Nalina Hamsaiyni Venkatesh, Data Steward

System and support:

• Erik Andersson
• Birgitte Brydsö
• Niklas Edmundsson (Tape coord)
• My Karlsson
• Roger Oscarsson
• Åke Sandgren
• Mattias Wadenstein (NeIC, Tier1)

HPC2N application experts¶

• HPC2N provides advanced and dedicated support in the form of Application Experts (AEs):
  • Jerry Eriksson: Profiling, Machine learning (DNN), MPI, OpenMP, OpenACC
  • Pedro Ojeda May: Molecular dynamics, Profiling, QM/MM, NAMD, Amber, Gromacs, GAUSSIAN, R, Python
  • Åke Sandgren: General high level programming assistance, VASP, Gromacs, Amber
  • Birgitte Brydsö: General HPC, R, Python
• Contact through regular support

HPC2N users by discipline¶

• Users from several scientific disciplines:
  • Biosciences and medicine
  • Chemistry
  • Computing science
  • Engineering
  • Materials science
  • Mathematics and statistics
  • Physics including space physics
  • ML, DL, and other AI

HPC2N users by discipline, largest users¶

• Users from several scientific disciplines:
  • Biosciences and medicine
  • Chemistry
  • Computing science
  • Engineering
  • Materials science
  • Mathematics and statistics
  • Physics including space physics
  • Machine learning and artificial intelligence (several new projects)

HPC2N users by software¶

Kebnekaise¶

The current supercomputer at HPC2N. It is a very heterogeneous system.

• Named after a massif (contains some of Sweden’s highest mountain peaks)

• Kebnekaise was

  • delivered by Lenovo and
  • installed during the summer 2016
  • Opened up for general availability on November 7, 2016
  • In 2018, Kebnekaise was extended with
    • 52 Intel Xeon Gold 6132 (Skylake) nodes, as well as
    • 10 NVidian V100 (Volta) GPU nodes
  • In 2023, Kebnekaise was extended with
    • 2 dual NVIDIA A100 GPU nodes
    • one many-core AMD Zen3 CPU node

• In 2024 Kebnekaise was extended with

  • 2 Dual socket GPU-nodes: Lenovo ThinkSystem SR675 V3
    • 2 x AMD EPYC 9454 48C 290W 2.75GHz Processor
    • 768GB [24x 32GB TruDDR5 4800MHz RDIMM-A]
    • 1 x 3.84TB Read Intensive NVMe PCIe 4.0 x4 HS SSD
    • 1 x NVIDIA H100 SXM5 700W 80G HBM3 GPU Board
  • 10 dual-socket GPU-nodes: ThinkSystem SR665 V3
    • 2 x AMD EPYC 9254 24C 200W 2.9GHz Processor
    • 384GB [24x 16GB TruDDR5 4800MHz RDIMM-A]
    • 1 x 1.92TB Read Intensive NVMe PCIe 5.0 x4 HS SSD
    • 2 x NVIDIA L40S 48GB PCIe Gen4 Passive GPU
  • 8 dual-socket CPU only: ThinkSystem SR645 V3
    • 2 x AMD EPYC 9754 128C 360W 2.25GHz Processor
    • 768GB [24x 32GB TruDDR5 4800MHz RDIMM-A]
    • 1 x 1 3.84TB Read Intensive NVMe PCIe 4.0 x4 HS SSD

Kebnekaise will be continuosly upgraded, as old hardware gets retired.

Current hardware in Kebnekaise¶

Kebnekaise have CPU-only, GPU enabled and large memory nodes.

The CPU-only nodes are:

• 2 x 14 core Intel skylake
  • 6785 MB memory / core
  • 52 nodes
  • Total of 87 TFlops/s
• 2 x 64 core AMD zen3
  • 8020 MB / core
  • 1 node
  • Total of 11 TFlops/s
• 2 x 128 core AMD zen4
  • 2516 MB / core
  • 8 nodes
  • Total of 216 TFlops/s

The GPU enabled nodes are:

• 2 x 14 core Intel skylake
  • 6785 MB memory / core
  • 2 x Nvidia V100
  • 10 nodes
  • Total of 75 TFlops/s
• 2 x 24 core AMD zen3
  • 10600 MB / core
  • 2 x Nvidia A100
  • 2 nodes
• 2 x 24 core AMD zen3
  • 10600 MB / core
  • 2 x AMD MI100
  • 1 node
• 2 x 24 core AMD zen4
  • 6630 MB / core
  • 2 x Nvidia A6000
  • 1 node
• 2 x 24 core AMD zen4
  • 6630 MB / core
  • 2 x Nvidia L40s
  • 10 nodes
• 2 x 48 core AMD zen4
  • 6630 MB / core
  • 4 x Nvidia H100 SXM5
  • 2 nodes
• 2 x 32 core AMD zen4
  • 11968 MB / core
  • 6 x Nvidia L40s
  • 2 nodes
  • Can only use 10 cores/GPU
• 2 x 32 core AMD zen4
  • 11968 MB / core
  • 8 x Nvidia A40
  • 2 nodes

The large memory nodes are:

• 4 x 18 core Intel broadwell
  • 41666 MB memory / core
  • 8 nodes
  • Total of 13.6 TFlops/s for all these nodes

GPUs can have different types of cores:

• CUDA cores: General-purpose cores for a variety of parallel computing tasks. Not as efficicent as specizalized cores. CUDA cores is only on NVidia. The (mostly) equivalent is called stream processors on AMD.
• Tensor cores: Made for matrix multiplications. Good for deep learning and AI workloads involving large matrix operations. Can be used for general-purpose as well, but less efficient for this. Tensor cores is the NVidia name. AMD has a somewhat equivalent core type called matrix cores.
• RT (ray tracing) cores: Cores that are optimized for tasks involving ray tracing, like rendering images or video.

GPU Type	CUDA cores / stream processors	TENSOR cores / matrix cores	RT cores
A40	10752	336
V100	5120	640
A100	6912	432
MI100	7680	480
A6000	10752	386
L40S	18176	568	142
H100	16896	528

NOTE that just like you cannot really compare CPU cores directly (speed etc.) you also cannot just compare CUDA/TENSOR/RT etc. cores directly (more efficient design, faster, etc.)

Kebnekaise - HPC2N storage¶

Basically four types of storage are available at HPC2N:

• Home directory
  • /home/X/Xyz, $HOME, ~
  • 25 GB, user owned
• Project storage
  • /proj/nobackup/abc
  • Shared among project members
• Local scratch space
  • $SNIC_TMP
  • SSD (170GB), per job, per node, “volatile”
• Tape Storage
  • Backup
  • Long term storage

Also

• SweStore — disk based (dCache)
  • Research Data Storage Infrastructure, for active research data and operated by NAISS, WLCG

Kebnekaise - projects¶

A compute project contains a certain amount of storage. If more storage is required, you must be a member of a storage project.

Projects are applied for through SUPR (https://supr.naiss.se).

I will cover more details in a later section, where we go more into detail about HPC2N and Kebnekaise.

HPC¶

High Performance Computing - opening the definition¶

Aggregating computing power¶

• 95 nodes totalling 4792 CPU cores and 84 GPUs (totalling 1055744 CUDA cores, 43076 TENSOR cores + 960 matrix cores, 4544 RT cores)
  • Compared to 4-8 cores in a common modern laptop + maybe 1 GPU

Higher performance¶

• More than 527,000,000,000,000 arithmetical operations per second (527 trillion (billion)) in the CPU cores
  • Compared to 200,000,000,000 Flops in a modern laptop (200 billion (milliard)

Solve large problems¶

• When does a problem become large enough for HPC?
• Are there other reasons for using HPC resources? (Memory, software, support, etc.)

High Performance Computing - large problems¶

A problem can be large for two main reasons:

• Execution time: The time required to form a solution to the problem is very long
• Memory / storage use: The solution of the problem requires a lot of memory and/or storage

The former can be remedied by increasing the performance

• More cores, more nodes, GPUs, …

The latter by adding more memory / storage

• More memory per node (including large memory nodes), more nodes, …
  • Kebnekaise: 128GB - 192GB, 384GB, 512GB, 768GB, 3TB
• Large storage solutions, …

High Performance Computing - what counts as HPC¶

High Performance Computing - other reasons¶

• Specialized (expensive) hardware
  • GPUs, including those optimized for AI
    • Kebnekaise has V100, A100, A40, MI100, A6000, L40S, H100
  • High-end CPUs (AVX-512 etc) and ECC memory
• Software
  • HPC2N holds licenses for several softwares
  • Software is pre-configured and ready-to-use
• Support and documentation

High Performance Computing - memory models¶

Two memory models are relevant for HPC:

• Shared memory: Single memory space for all data.


  • Everyone can access the same data
  • Straightforward to use
• Distributed memory: Multiple distinct memory spaces.


  • Everyone has direct access only to the local data
  • Requires communication

High Performance Computing - programming models¶

The programming model changes when we aim for extra performance and/or memory:

• Single-core: Matlab, Python, C, Fortran, …
  • Single stream of operations
• Multi-core: Vectorized Matlab, pthreads, OpenMP
  • Multiple streams of operations
  • Work distribution, coordination (synchronization, etc), …
• Distributed memory: MPI, …
  • Multiple streams of operations
  • Work distribution, coordination (synchronization, etc), …
  • Data distribution and communication
• GPUs: CUDA, OpenCL, OpenACC, OpenMP, …
  • Many lightweight streams of operations
  • Work distribution, coordination (synchronization, etc), …
  • Data distribution across memory spaces and movement

High Performance Computing - software¶

Complexity grows when we aim for extra performance and/or memory/storage:

1. Single-core: LAPACK, …
   • Load correct toolchain etc
2. Multi-core: LAPACK + parallel BLAS, …
   • Load correct toolchain etc
   • Allocate correct number of cores, configure software to use correct number of cores, …
3. Distributed memory}: ScaLAPACK, …
   • Load correct toolchain etc
   • Allocate correct number of nodes and cores, configure software to use correct number of nodes and cores, …
   • Data distribution, storage, …
4. GPUs: MAGMA, TensorFlow, …
   • Load correct toolchain etc
   • Allocate correct number of cores and GPUs, configure software to use correct number of cores and GPUs, …
